PocketChiller

ULK 402 NP

Mini Recirculating Chiller

Eco-friendly cooling in a compact format – the PocketChiller stands out with its low weight, quiet operation, use of natural refrigerants and a powerful pump performance. An ideal solution for sustainable cooling in laboratories, research, industry and production.

NEU mit natürlichem Kältemittel

from 2.425,- €

Preise exkl. MwSt. zzgl. Versandkosten
Lieferzeit: 3 - 5 Werktage

Working temperature range:	-10°C ... +40°C
Cooling capacity:	400 W
Flow rate:	6 l/min
Flow pressure:	0,8 bar
Refrigerant:	R290

Product features

Electronic temperature control with LED display
Natural refrigerant with high efficiency reduces power consumption
Reduced refrigerant charge
Low operating noise
Fill level indicator on the front of the unit
Fill level monitoring with automatic pump shut-off
Hermetically sealed, air-cooled and low-maintenance refrigeration unit
Visual and audible alarm
Easily accessible filling opening and hose connections on the top of the unit
Lightweight and compact housing
Suitable for use with non-flammable coolants

Feature-Highlights
Focused on the Details

User-Friendly Handling

Proven control system with easy-to-read LED display and intuitive operation. The filling opening and hose connections are conveniently located on the top of the unit, making filling and connection straightforward. Three different hose connector sizes included for maximum flexibility.

Integrated Fill Level Indicator

The clearly visible fill level indicator on the front allows for quick and easy monitoring. If the level drops too low, the pump automatically shuts off to prevent damage.

Innovative Housing Design

The housing, made of rigid polyurethane foam (PUR), offers excellent thermal properties and high stability. Its low weight makes handling particularly easy. Thanks to the well-thought-out construction with an integrated reservoir for the thermal fluid, the unit remains compact and space-efficient.

Naturally cool:
Environmentally friendly through the use of natural refrigerants

sustainable

Future-proof cooling systems that are not affected by the ban on fluorinated refrigerants
Lower refrigerant charge per unitt
Significantly reduced GWP (Global Warming Potential)

economical

Energy-efficient fans
Replaces mains water coolingr
Cost-effective, readily available refrigerant with high efficiency
Reduced power consumption thanks to natural refrigerants

By using natural refrigerants, we are committed to sustainable and future-ready cooling solutions. Compared to synthetic and fluorinated alternatives, they offer a significantly lower global warming potential.

Our recirculating chillers already meet future environmental standards – efficient, economical and resource-conscious.

Produktinformationen
Technische Daten, Zubehör & Downloads

Working temperature range:	-10°C to +40°C
Control accuracy at -10°C:	+/- 1 K
Display resolution:	0,1 K
Cooling capacity at 20°C:	400 W
Cooling capacity at 10°C:	350 W
Cooling capacity at 0°C:	250 W
Cooling capacity at -10°C:	80 W
Flow rate [max.]:	8 l/min
Flow pressure [max.]:	0,8 bar
Hose connections:	G 1/4"
Coolant tank:	1,5 bis 4,0 l
External dimensions [WxDxH]:	26 x 37 x 40,5 cm
Installation dimensions [WxD]:	66 x 57 cm

Weight:	19 kg
Noise level [distance 1m]:	47 dB(A)
Permitted ambient temperature range:	5°C bis 40°C
Max. permissible temperature of the coolant:	60°C
Electrical connection:	230 V / 50 Hz
Power consumption:	200 W
Current [max.]:	1,6 A
Protection class:	IP 20
Class. acc. DIN 12876:	I / NFL
Max. operating pressure:	25 bar
Refrigerant:	*R290 (GWP 3)**
Minimum room volume of the installation space:	8 m³
