ProChiller

ULK 602 N

Recirculating Chiller | Circulating cooler

High-quality, eco-friendly and versatile – the ProChiller adapts perfectly to your individual requirements thanks to a wide range of configuration options. Its user-friendly operation and quiet performance make it ideal for use in laboratories and other demanding environments.

NEU mit natürlichem Kältemittel

from 3.425,- €

Preise exkl. MwSt. zzgl. Versandkosten
Lieferzeit: ab Lager oder 2-5 Werktage

Working temperature range:	-10°C ... +40°C
Cooling capacity:	600 W
Flow rate:	10 l/min
Flow pressure:	0,6 bar
Refrigerant:	R290

Product features

High-quality components

Touchscreen controller with glass surface and integrated digital display for fill level and pump status
Brand-name components for long service life
Hermetically sealed, air-cooled, and low-maintenance refrigeration unit

Environmentally friendly

Energy-efficient fan with EC technology
Natural refrigerant with high efficiency reduces power consumption
Reduced refrigerant charge per unit

User-friendly

Easy filling and draining thanks to integrated filling funnel and drain valve
Leak-free hose replacement with self-sealing quick-connect fittings
No side ventilation grilles – ideal for space-saving installation

Low operating noise

Exceptionally quiet components
Fan speed automatically adjusts to cooling demand

Operational safety

Freeze and overheat protection
Automatic pump shut-off in case of low coolant level
Visual and audible alarms
Clear-text error messages for quick diagnostics

Feature-Highlights
Focused on the Details

User-friendly operation

Self-sealing hose connectors allow for leak-free hose changes without any spillage of the coolant. Thanks to practical quick couplings, the hose can be replaced quickly and without the need for tools. The integrated filling funnel and drain valve make filling and draining the system simple and convenient.

High-quality controller

The proven control unit features a high-quality touchscreen with a glass surface. It includes a digital display for fill level and flow rate. Clear status and error messages in plain text, along with visual and audible alarms, provide additional safety and ensure smooth operation.

Optional features

The ProChiller can be tailored to your specific needs with a wide range of options: Expand the control system with additional interfaces such as MODBUS, voltage input or -output, or take advantage of external temperature sensing for even greater temperature stability. A mobile version or an alternative pump are also available, allowing you to configure the cooling solution that fits your application perfectly.

Naturally cool:
Environmentally friendly through the use of natural refrigerants

sustainable

Future-proof cooling systems that are not affected by the ban on fluorinated refrigerants
Lower refrigerant charge per unitt
Significantly reduced GWP (Global Warming Potential)

economical

Energy-efficient fans
Replaces mains water coolingr
Cost-effective, readily available refrigerant with high efficiency
Reduced power consumption thanks to natural refrigerants

By using natural refrigerants, we are committed to sustainable and future-ready cooling solutions. Compared to synthetic and fluorinated alternatives, they offer a significantly lower global warming potential.

Our recirculating chillers already meet future environmental standards – efficient, economical and resource-conscious.

Produktinformationen
Technische Daten, Zubehör & Downloads

Working temperature range:	-10°C to +40°C
Control accuracy at -10°C:	+/- 0,5 K
Display resolution:	0,1 K
Cooling capacity at 20°C:	600 W
Cooling capacity at 10°C:	500 W
Cooling capacity at 0°C:	350 W
Cooling capacity at -10°C:	200 W
Flow rate [max.]:	10 l/min
Flow pressure [max.]:	0,6 bar
Hose connections:	12,7 mm
Coolant tank:	1,5 to 4,0 l
External dimensions [WxDxH]:	31 x 41,5 x 58,5 cm
Installation dimensions [WxD]:	31 x 71,5 cm

Weight:	28 kg
Noise level [distance 1m]:	49 dB(A)
Permitted ambient temperature range:	5°C to 40°C
Max. permissible temperature of the coolant:	60°C
Electrical connection:	230 V / 50 Hz
Power consumption:	380 W
Current [max.]:	3,0 A
Protection class:	IP 20
Class. acc. DIN 12876:	I / NFL
Max. operating pressure:	25 bar
Refrigerant:	*R290 (GWP 3)**
Minimum room volume of the installation space:	12 m³

RS485 interface for MODBUS communication

Enables integration into control systems.

RS485 interface for ST-Bus communication

Allows easy reading and modification of values. The manufacturer’s software is available free of charge and enables operation even without prior experience with bus protocols.
(Note: A gateway—available as an optional accessory—is required for connection via USB or RS232.)

Voltage input for external setpoint control

Allows direct control of the temperature via external input signals.

Voltage output for actual value transmission

Transmits the current temperature values to an external system.

Potential-free contact

Enables connection to an external alarm system for enhanced safety.

Direct temperature measurement in your application

An external sensor measures the temperature directly at the process point. Automatic adjustment of the setpoint ensures particularly stable temperature control and greater process reliability compared to standard systems.

Mobile version

Greater flexibility with four castors, two of which are lockable.

Hoses
